SIBOM Skid Steer Snow Blade Attachment, 30° Hydraulic Angling, Adjustable Skid Shoes, NM500 Steel Cutting Edge, Spring-Loaded Trip Mechanism

SIBOM Skid Steer Snow Blade Attachment, 30° Hydraulic Angling, Adjustable Skid Shoes, NM500 Steel Cutting Edge, Spring-Loaded Trip Mechanism

$1,999.99 - $2,899.99
$1,999.99
$1,999.99 - $2,899.99
$1,999.99
SKU
Choose a Model
  • The Sibom snow plow is an essential piece of snow removal equipment for modern highways, urban sanitation, airports, and more.
  • Our company’s snow plow features a dependable, well-designed structure and advanced technology, making it suitable for a wide range of snow-clearing tasks.
  • Equipped with a spring adjustment mechanism and automatic blade return after obstacle avoidance, which is particularly effective for use in both urban and rural environments, as well as municipal sanitation settings.
  • The plow comes with a replaceable wear-resistant cutting edge made of high-strength NM500 steel, ensuring excellent durability, wear resistance, and impact resistance.
Product Feature
  1. The snow plow integrates with skid steer loaders using a quick-attach system, enabling installation and removal within two minutes. It features left and right angling as well as forward and backward obstacle-avoidance functionality. The mounting frame adopts a box-type structure for high structural strength and smooth operation. The snow blade is essential equipment for modern highways, urban sanitation, and airports. Our snow blades are designed with a reliable structure and advanced technology, making them suitable for various snow-clearing tasks.
  2. The dual-action hydraulic cylinders allow the blade to pivot ±30° to the left or right, ensuring that snow rolls to one side during high-speed plowing while reducing impact on the blade.
  3. The plow is equipped with imported Italian Faster quick couplers, complete with dust caps. These couplers offer stable quality and are easy to assemble and disassemble.
  4. The spring is made of low-temperature-resistant, impact-resistant, and wear-resistant spring steel. It provides high tension to ensure proper snow-clearing performance while enabling the blade to return to its original position quickly after overcoming obstacles.
  5. The snow plow uses hydraulic control for left and right angling with a pivot range of ±30°, allowing easy and quick changes to the snow-clearing direction. This makes it particularly effective for clearing light snow from sidewalks and narrow roads.
  6. The plow features a reinforced steel structure with a replaceable wear-resistant cutting edge. The cutting edge is bolted to the blade for quick and easy replacement. Nylon cutting edges are also available as an option.
  7. The blade automatically flips when encountering obstacles, preventing damage to the equipment. After overcoming the obstacle, the blade automatically returns to its original position with the help of the spring mechanism.
  8. Optional accessories include width markers and a front guard plate.
  9. When paired with small loaders, customers are advised to install bucket-positioning stops (bucket lock) according to their loader's configuration.
Performance Introduction
  1. Snow blade mechanism and skid steer loader adopts quick link, disassembling and assembling is completed within 2 minutes, snow blade has left and right swing, front and rear overall obstacle avoidance function. The connecting frame adopts box-type structure, high structural strength, smooth movement; snow removal board is the modern highway, city sanitation, airports and other places must be equipped with snow removal equipment, our company produces the snow removal board structure is reasonable and reliable, advanced technology, can be applied to a variety of occasions of snow removal work.
  2. Double-acting double hydraulic cylinders can achieve the shovel plate left and right deflection ± 30 degrees, to ensure that the snow rolls to one side when pushing the snow quickly, and at the same time reduce the impact of snow on the shovel body.
  3. Imported Italian ‘Faster’ quick coupling, equipped with dust cap, stable quality, easy to disassemble.
  4. Spring adopts spring steel with low temperature resistance, impact resistance and certain wear resistance, with large pulling force, which can meet the working pulling force of shovel body when clearing snow normally, and also ensure that the shovel body can return to the position quickly after crossing the obstacles.
Specifications
Model ssbd60 ssbd72 ssbd84 ssbd96
Width (in) 60 72 84 96
Length (in) 39.8 39.8 39.8 39.8
Height (in) 25 25 25 25
Job Width at 30°   (in) 51.2 62.2 72.6 82.7
Deflection Angle (degrees) ±30 ±30 ±30 ±30
Weight (including pendant) (lbs) 617.3 650.4 687.8 716.5
Height of Obstacle Avoidance (in) ≤31.5 ≤31.5 ≤31.5 ≤31.5
Maximum Allowable Pressure (psi) 3045.8 3045.8 3045.8 3045.8
Hanging model Skid steer loader Skid steer loader /loader
Machine Configurations
Serial No. Main Configuration Specification/Model
1 Hydraulic Cylinder 63-32x176x424
2 Quick Coupler G3/4 G1/4
3 Hydraulic Hose F381 24° Cone
4 Wear-resistant Cutting Edge NM500
5 Spring 60Si2Mn
Warranty We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.
